Hypertherm ArcGlide Torch Height Control User Manual

ArcGlide THC Instruction Manual 2-11
INSTALLATION
2
System description for a discrete configuration
The following diagram illustrates the cable and signal connections in a discrete communication configuration.
Note: For information on multidrop configurations, refer to the instruction manual for your plasma system.
Discrete control and signal cables
Customer-supplied operator console
(optional)
Station on/off/program switch
Station active light
Lifter up/down switch
Lifter
HMI
Control module
CNC
Plasma system
Key:
Hypernet connection
Discrete connection
