ArcGlide THC Instruction Manual 2-17
ArcGlide THC with discrete connection to a generic CNC and HPR400XD
Shielded Ethernet cable
ArcGlide control module
address 1
ArcGlide HMI address 1
To CNC RS-422 port, terminate as
required
CNC I/O cable
Plasma interface cable
Lifter interface cable
ArcGlide lifter
DB50 male
Cable 223192 without serial
(with red heatshrink)
Arc
voltage
sense
wires
Plasma interface (090052)
DB37 female
Axes 3,4
Axes 1,2
I/O
Generic CNC with
serial communication
RS-422 serial port
OEM-supplied cable
2
