MAINTENANCE
Printed circuit board (PCB) block diagrams
PCB block diagram for a Hypernet configuration
HPR plasma system with Hypernet
HMI (optional)
Hypernet interface
HMI Processor PCB
LCD character module
Front panel LEDs
7-segment display interface
HMI 7-segment display
PCB
Board interconnect
THC Processor PCB
LCD character module
Front panel LEDs
Hypernet interface
THC interface PCB
Lifter interface
Op-con interface
Plasma interface
Board interconnect
Lifter interface PCB
Lifter interface
Motor brake encoder interface
Upper/lower limit switches
Tip touch
Station enable switch
Manual up/down switch
Breakaway switch
Laser pointer
Station active light
Control module
Lifter
Hypernet interface
CNC with Hypernet
Hypernet interface
Plasma interface PCB*
Arc voltage
* Contact closure outputs from THC
* Contact closure inputs to THC
Plasma interface
Industrial
Ethernet switch
Key:
Hypernet connection
Discrete connection
* See the HPR Instruction Manual for information about how to
install the plasma interface PCB with Hypernet interface.
