Hypertherm ArcGlide Torch Height Control User Manual

4-6 ArcGlide THC Instruction Manual
MAINTENANCE
Flow of ArcGlide operations
The flowchart on the following pages illustrate the sequence of states in the operation of an ArcGlide THC.
Flow of ArcGlide operations
Setups were saved the last
time the THC shut down.
Immediately after the
THC powers ON, hold
the display select arrows
on the front of the control
module to restore defaults
or to enter built-in test
modes.
Power OFF then
power ON to end test
mode.
Power OFF then
power ON to end test
mode.
Power ON reset
Initialize uP clock, on-chip I/O, expansion
I/O.
Read stored setup parameters from
Flash.
Display splash screen.
Initialize Hypernet links.
Initialize watchdog timer.
Main loop
Both up and down
display arrows?
Restore default setup
parameters
yes
no
Lifter friction test
Up display arrow?
yes
no
Down
display
arrow?
Lifter cycle test
yes
no
