Hypertherm ArcGlide Torch Height Control User Manual

2-16 ArcGlide THC Instruction Manual
DB37F
DB37M
DB37F
To CNC RS-422 port,
terminate as required
OEM-supplied
serial cable
DB37 female
HPR control PCB
DB37 male
Cable 223192
without serial
(with red
heatshrink)
Plasma interface (090052)
CNC I/O cable
Shielded Ethernet cable
ArcGlide control module
address 1
Plasma interface cable
Arc voltage sense
wires
Lifter interface cable
ArcGlide lifter
To plasma interface
assembly
Cable 223192
without serial
(with red
heatshrink)
OEM-supplied serial
cable
DB37 female
RS-422 serial port
DB50 male
ArcGlide HMI
address 1
Generic CNC with serial communication
Axes 3,4
Axes 1,2
I/O
ArcGlide THC with discrete connection to a generic CNC and HPR or HPRXD plasma system
2
