3-16 ArcGlide THC Instruction Manual
OPERATION
HMI Parameter Value
Critical Errors
ERR 23 INPUT VOLTAGE LOW The incoming AC line voltage is more than
20% low.
ERR 24 INPUT VOLTAGE HIGH The incoming AC line voltage is more than
15% high.
ERR 25 OVER TEMPERATURE The maximum temperature for the processor
has exceeded the maximum value.
ERR 26 MOTOR DRIVE The maximum temperature for the motor drive
has been exceeded.
ERR 27 INTERLOCK TRIPPED Safety interlock was removed.
ERR 28 BREAKAWAY TRIPPED Torch breakaway was removed.
ERR 29 FIELD SUPPLY FAILED The +5 V, +12 V, or -12 V supply has failed.
ERR 30 LIFTER CALIBRATION Lifter Calibration down motion failed after
power ON.
ERR 31 NO HYPERNET CONNECTION There is no Hypernet connection to either the
HMI or CNC.
ERR 32 LOST CNC HYPERNET The CNC Hypernet connection was lost after
it was established.
ERR 33 LOST HMI HYPERNET The HMI Hypernet connection was lost after it
was established.
ERR 34 ENCODER OVERFLOW Height position error.
ERR 35 ENCODER UNDERFLOW Height position error.
ERR 36 HYPERNET ADDRESSING Hypernet communication error, check unit
addressing.
