J6 CNC interface
Pin number Signal Pin number Signal
1 Cycle Start input + 20 THC Error output B
2 Cycle Start input – 21 Torch Breakaway output A
3 Low gain input + 22 Torch Breakaway output B
4 Low gain input – 23 CNC Spare output A
5 AVC Disable input + 24 CNC Spare output B
6 AVC Disable input – 25 Interlock input +
7 IHS Sync input + 26 Interlock input –
8 IHS Sync input – 27 Interlock output A
9 Spare Input 1 + 28 Interlock output B
10 Spare Input 1 – 29 Common
11 Spare Input 2 + 30 Common
12 Spare Input 2 – 31 Common
13 IHS Complete output A 32 Common
14 IHS Complete output B 33 +24 VDC output
15 Retract complete output A 34 +24 VDC output
16 Retract complete output B 35 +24 VDC output
17 Machine Motion output A 36 and 37 Not connected
18 Machine Motion output B
19 THC Error output A
J7 Op-Con interface
Pin number Signal
1 Not connected
2 Manual disable switch input +
3 Manual select switch input +
4 Torch up switch input +
5 Torch down switch input +
6 Spare switch input +
7 Common
8 Torch enabled output A
9 Torch enabled output B
10 Error output A
11 Error output B
12 Spare output A
13 Spare output B
14 Power +24 VDC output
