4-52 ArcGlide THC Instruction Manual
MAINTENANCE
J5 LCD Character module
Pin number Signal
1 DB6
2 DB7
3 DB4
4 DB5
5 DB2
6 DB3
7 DB0
8 DB1
9 WR\
10 E1 (lines 1 and 2)
11 Vee
12 RS
13 VOC
14 Vss
15 Not connected
16 E2 (lines 3 and 4)
J4 Display backlight
Pin number Signal
1 +5 V
2 Ground
3 Not connected
J11 Power connector
Pin number Signal
1 +5 VDC
2 Ground
3 Common
4 Not connected
J8 Hypernet
Pin number Signal
1 TX + (transmit data +)
2 TX – (transmit data –)
3 RX + (receive data +)
4 Not connected
5 Not connected
6 RX – (receive data –)
7 Not connected
8 Not connected
J10 DB9 RA Female
Pin number Signal
1 Not connected
2 TX out
3 RX in
4 Not connected
5 Ground
6 Not connected
7 Not connected
8 Not connected
9 Not connected
