4-58 ArcGlide THC Instruction Manual
MAINTENANCE
J5 Plasma I/O cable (blue)
Pin number Signal
1 RS422 RX –
2 RS422 RX +
3 RS422 TX –
4 RS422 TX +
5 RS422 common
6 Motion input +
7 Input common –
8 Error input +
9 Input common –
10 Rampdown error input +
11 Input common –
12 Not ready input +
13 Input common –
14 Spare input +
15 Input common –
16 Corner output A
17 Corner output B
18 Pierce output A
19 Pierce output B
20 Hold output A
21 Hold output B
22 Start output A
23 Start output B
24 Spare output A
25 Spare output B
26 Remote on output A
27 Remote on output B
28 Common
29 Common
30 Common
31 +24 VDC
32 +24 VDC
33 +24 VDC
34 1/50 Arc voltage +
35 1/50 Arc voltage –
36 and 37 Not connected
