4-60 ArcGlide THC Instruction Manual
MAINTENANCE
* The arc voltage terminals on connector J4 must be
connected to the I/O board in the plasma supply.
J4 Arc voltage*
Pin number Signal
1 Work +
2 Electrode –
J5 CNC interface
Pin number Signal
1 HPR RX –
2 HPR TX –
3 RS422 Common
4 Motion
5 Error
6 Rampdown error
7 HPR not ready
8 Not connected
9 Not connected
10 Not connected
11 Not connected
12 Spare
13 Pierce A
14 Hold A
15 Start A
16 Not connected
17 Not connected
18 Ground
19 Not connected
20 HPR RX +
21 HPR TX +
22 Not connected
23 Motion
24 Error
25 Rampdown error
26 HPR not ready
27 Not connected
28 Not connected
29 Not connected
30 Not connected
31 Spare
32 Pierce B
33 Hold B
34 Start B
35 Not connected
36 Ground
37 Not connected
J6 Remote ON/OFF
Pin number Signal
1 ON/OFF out+
2 ON/OFF out –
2
