4-62 ArcGlide THC Instruction Manual
MAINTENANCE
J5 Torch tip
Pin number Signal
1 Ohmic torch tip
2 Ohmic torch tip
J10 Lifter I/O cable (red)
Pin number Signal
1 Motor +
2 Motor –
3 Brake –
4 Common –
5 Power +24 VDC
6 Ohmic contact sense common
7 Ohmic contact sense
8 Ohmic contact sense bias -12 VDC
9 Encoder common
10 +5 V Station active
11 Encoder input B –
12 Encoder input B +
13 Encoder input A –
14 Encoder input A +
15 Field common
16 Change consumable switch +
17 Lifter down switch +
18 Lifter up switch +
19 Breakaway switch +
20 Upper limit switch +
21 Lower limit switch +
22 Not connected
23 Common
24 Not connected
J6 Motor brake encoder
Pin number Signal
1 Motor +
2 Motor –
3 Not connected
4 Not connected
5 Brake +24 VDC
6 Brake switch return
7 +5 VDC
8 Phase A+
9 Phase A –
10 Phase B+
11 Phase B –
12 Common
J7 Laser pointer
Pin number Signal
1 +5 VDC
2 Common
J8 Station enable switch
Pin number Signal
1 Station enable
2 Common
J9 Up/down switch
Pin number Signal
1 Up switch
2 Common
3 Down switch
4 Not connected
