Hypertherm ArcGlide Torch Height Control User Manual

6-2 ArcGlide THC Instruction Manual
WIRING DIAGRAMS
Battery Cap, polarized Cap, non-polarized Cap, feed-thru Circuit breaker Coax shield Current Sensor Current sensor Diode Door interlock Fan Feedthru LC Filter, AC DC supply
Fuse Ground Clamp Ground, Chassis Ground, Earth IGBT Inductor LED Lamp Pin Socket Plug PNP Transistor Potentiometer
Push Button, Normally Closed
MOV
Push Button, Normally Open Receptacle Relay, Coil Relay, Normally Closed Relay, Normally Open Relay, Solid State, AC Relay, Solid State, DC Relay, Solid State, Dry SCR Shield Shunt Spark Gap Resistor

Hypertherm ArcGlide Torch Height Control Specifications

General

Brand	Hypertherm
Model	ArcGlide Torch Height Control
Category	Cutter
Language	English
