ArcGlide THC Instruction Manual 2-7
INSTALLATION
Example of a good cutting table ground bus.
The picture above shows the connection from the gantry ground bus, the connection from the ground rod, the plasma
system positive lead, the RHF console*, the CNC enclosure, the torch holder, and the plasma system chassis.
* Applies to systems that use a remote high frequency (RHF) console
Gantry
Ground rod
Plasma
system lead
(+)
