ArcGlide THC Instruction Manual 2-47
INSTALLATION
Pin number Color Signal name
16 Red Corner output A
17 Green Corner output B
18 Red Pierce output A
19 Blue Pierce output B
20 Red Hold output A
21 Yellow Hold output B
22 Red Start output A
23 Brown Start output B
24 Red Spare output A
25 Orange Spare output B
26 Red Remote on output A
27 White Remote on output B
28 Green Common
29 Blue Common
30 Green Common
31 Yellow +24 VDC output
32 Green +24 VDC output
33 Brown +24 VDC output
34 Green 1/50 Arc voltage +
35 Orange
1/50 Arc voltage
–
36 and 37 Not connected
