MAPs Reference Tables
Reference Table 1, Model A00 Error Messages
Table 17. Model A00 Error Messages
Message Description Action
01 END OF FORMS Forms do not load when Load/Form Feed
key is pressed.
No forms movement.
See “MAP 0130: No Paper Movement” on
page 62.
01 END OF FORMS Forms are visible between the printhead
and the platen.
Forms path sensor cannot sense paper.
See “MAP 0131: Paper Path Sensor” on
page 66.
02 FORMS JAM
CHECK PATH
ASF paper path LED flashes
A forms jam was detected by one of the
forms sensors.
See “MAP 0110: Automatic Sheet Feeder”
on page 26.
02 FORMS JAM
CHECK PATH
Any paper path LED except ASF flashes
A forms jam was detected by one of the
forms sensors.
See “MAP 0190: Form Feed Problems” on
page 101.
11 LOAD BIN 1, 2, or 3
False message
Paper begins to feed from any bin, but
stops.
Rear (under platen) path sensor cannot
sense paper.
See “MAP 0131: Paper Path Sensor” on
page 66.
20 DSR ERROR
CHECK INTF
Host DATA SET READY signal not sensed
by the serial interface.
See “MAP 0120: Parallel or Serial
Attachment, Model A00 and Model 003” on
page 33.
Chapter 1. Diagnosing Problems
133
