MAP 0110: Automatic Sheet Feeder
Symptom Explanation Suspected FRUs/Causes
02 FORMS JAM
099 FORMS JAMMED
Automatic Sheet Feeder (ASF) failures
Paper or debris in forms path
Mechanical
Main paper feed
Printer logic board
Cable
Stacker
Bins
Before starting this map:
1. Ensure that the ASF cable is plugged into the stacker.
2. Fan the paper in the paper bins.
3. Ensure the ASF assembly is installed correctly.
The ASF assembly has 2 hook latches that fit into 2 slots on the printer rear frame directly behind the platen.
For detailed ASF installation instructions, see:
v
IBM 4247 Printer Automatic Sheet Feeder Guide
, SA24-4407
- and -
v
IBM 4247 Printer Model A00 User’s Guide
, SA24-4404
-or-
v
IBM 4247 Printer Models 001, 002 User’s Guide
, SA24-4408
-or-
v
IBM 4247 Printer Model 003 User’s Guide
, S544–5780
4. Ensure the paper load lever on each ASF bin is closed:
Chapter 1. Diagnosing Problems 26
