MAP 0180: Top Cover Interlock
Symptom Explanation Suspected FRUs/Causes
96 COVER OPEN
90 CLOSE COVER
096 NOT READY COVER OPEN
T&D19 TOP COVER INTERLOCK TEST FAILURE
Top cover
Top cover magnet
Operator panel
Printer logic board
Operator panel cable
ASF stacker assembly
ASF stacker assembly cable
Table 14. MAP 0180: Top Cover Interlock
Step Questions/Actions Yes No
1.
Is the top cover for the ASF stacker assembly
installed?
Go to step 2 on page 99. Go to step 3 on page 100.
Chapter 1. Diagnosing Problems
98
To Next Page
