Table 13. MAP 0170: ASF Stacker (continued)
Step Questions/Actions Yes No
7. 1. Remove the stacker assembly.
2. Install the stacker/ASF loop-back connector in the
stacker connector.
3. Run T&D10 in Single Test Mode to test the stacker
circuits. For Model A00, see “How To Run the Test
and Diagnostic (T&D) Programs” on page 161. For
Models 001, 002, or 003, see “How To Run the Test
and Diagnostic (T&D) Programs” on page 201.
Does T&D10 run without errors?
Remove the stacker/ASF
loop-back connector.
Install a new stacker assembly.
Run T&D in automatic mode to
verify correct printer operation.
For Model A00, see “How To
Run the Test and Diagnostic
(T&D) Programs” on page 161.
For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Remove the stacker/ASF
loop-back connector.
Install a new logic board. For
Model A00, see “Logic Board -
Model A00” on page 370. For
Models 001 and 002, see “Logic
Board - Models 001 and 002” on
page 378. Or “Logic Board -
Model 003” on page 366.
-or-
Install a new stacker cable.
Run T&D in Automatic Test
Mode to verify correct printer
operation. For Model A00, see
“How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002,
or 003, see “How To Run the
Test and Diagnostic (T&D)
Programs” on page 201.
