Assembly 2: Tractor Assembly, Automatic Sheet Feeder, and Stacker
1
2
7
9
8
6
11
10
4
5
3
E90APC11
Asm–
Index
Part
Number Units Description
2–1 63H6069 1 Tractor Assembly
–2 08H7090 1 Stacker Assembly
–3 08H6955 1 2nd or 3rd Bin, Automatic Sheet Feeder Assembly
Chapter 6. Parts Catalog
463
