MAP 0131: Paper Path Sensor
Symptom Explanation Suspected FRUs/Causes
01 END OF FORMS
001 END OF FORMS
11 LOAD BIN 1, 2, or 3
011 CHECK/LOAD BIN 1, 2, or 3
031 END OF FORMS TIMEOUT
Paper sensor failure
Logic board
Sensor cable assembly
Table 9. MAP 0131: Paper Path Sensor
Step Questions/Actions Yes No
1.
Try to load forms from the failing forms path.
Does the form load, and is it visible between the
printhead and the platen?
Go to step 2. You are in the wrong MAP.
Return to “MAP 0100: START
OF CALL” on page 23.
2.
Are you trying to load black back forms? Go to step 3. Go to step 4 on page 67.
3.
Black back forms will not work in all forms paths, and
can cause false forms path sensor errors.
Are you trying to load black back forms in the front
push, rear pull, or push-pull forms paths?
Black back forms will not work
in the front push, rear pull, or
push-pull forms paths.
Select another forms path.
Go to step 4 on page 67.
Chapter 1. Diagnosing Problems
66
