MAP 0170: ASF Stacker
Symptom Explanation Suspected FRUs/Causes
02 FORMS JAM
97 STACKER ERROR
087 STACKER ERROR
099 FORMS JAMMED
Stacker Failures
Mechanical parts
Printer logic board
ASF stacker assembly
ASF stacker cable assembly
Table 13. MAP 0170: ASF Stacker
Step Questions/Actions Yes No
1.
Are you here due to a ’02’, ’97’, ’087’, or ’099’
display message?
Go to step 6 on page 96. Go to step 2.
2.
The forms guide metal deflector must be in the open
(down) position when feeding paper from the ASF bins
or from the manual sheet feed tray. See step 3 on
page 302.
Is the forms guide metal deflector open?
Go to step 3 on page 95. Repair as needed.
Run T&D in Automatic Test
Mode to verify correct printer
operation. For Model A00, see
“How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002,
or 003, see “How To Run the
Test and Diagnostic (T&D)
Programs” on page 201.
Chapter 1. Diagnosing Problems
94
