Chapter 2. Diagnostics

Test and Diagnostic Information - Model A00

How To Print the Print Test

1. Load forms.

2. Power off (O) the printer.

3. Press and hold the Online key while powering on the printer.

4. Press and hold the Online key until the printer has stopped all motion (approximately 20 seconds).

5. Release the Online key, and the message PRINT TEST displays. The Print Test will start printing.

6. To stop the Print Test at any time, press the Online key.

Note: This test will print using the currently selected font. To change the font, see the

IBM 4247 Printer Model

A00 User’s Guide

, SA24-4404.

How To Print Firmware Part Number and Version Levels

1. Print the Print Test. See “How To Print the Print Test”.

2. Line 3 of the printout shows the printer firmware part number. Code module (U54) and generator module

(U02) version levels follow the part number.

How To Print the Power On Configuration

1. Load forms.

2. Power off (O) the printer.

3. Press and hold the Menu/Enter key while powering on the printer.

4. Press and hold the Menu/Enter key until the printer has stopped all motion (approximately 20 seconds).

5. Release the Menu/Enter key, and the message PRINT OUT=NO will display.

6. To print the current settings, press the Pitch key. The message PRINT OUT=YES will display, and the

Configuration Setup Printout is printed.
