IBM 4247

Index
A
adjustments
AFTA 282
bidirectional printing 294
carriage drive belt tension 280
carriage support shaft 280
first line printing 294
listing of 279
paper feed drive belt tension 281
sensor 208, 296
tear-off line 295
Adjustments 275, 279
AFTA
adjustment 282
calibration 282
motor wiring 250
remove/install 407
service check 286
ASF
MAP 26
service check 319
attachment, Model A00
about 33
connectors
parallel attachment 262
serial attachment 262
MAP 33
remove/install
parallel attachment 370, 378
serial attachment card 390
attachment, Models 001 and 002
about 41
attachment, Models 001 and 002
(continued)
attachment card microcode module
location 269
identification
coax attachment card 54
twinax attachment card 54
MAP 41
remove/install
coax attachment card 392
twinax attachment card 396
attachment, network print server (NPS) -
MAP 59
Attachment Card Guide Assembly,
Removal & Installation 364
Attachment Cards, Model 003; Removal
& Installation 359
B
Base Code Compatibilities 157
belt
carriage drive
adjustment 280
remove/install 420
service check 279
paper feed drive
adjustment 281
remove/install 448
upper feed roller drive
remove/install 426
bidirectional printing adjustment
about 294
bidirectional printing adjustment
(continued)
Bidirectional Adjustment Test - T&D16,
Model A00 178
Bidirectional Adjustment Test - T&D16,
Models 001 and 002 217
C
cable, power 481
cable diagrams 258
carriage drive belt
adjustment 280
remove/install 420
service check 279
carriage motor
remove/install 415
wiring 246
catalog, parts 457
Circuit Diagrams 240
configuration
changing a value in the power on
configuration menu 486
changing a value in the printer
configuration menu 504
changing a value in the program
configuration menu 493
coax configuration printout
defaults 500
power on configuration menu
chart 485
power on configuration printout
defaults 485
© Copyright IBM Corp. 1995, 2001
561
