IBM 4247 User Manual

T&D Error Messages and Actions – Models 001, 002, and 003
Table 28. T&D Error Messages and Actions
Error Message Description Action
ERROR RAM
TEST
RAM Error Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
ATTACHMENT
CARD IS NOT
COMPATIBLE
WITH PRINTER
BASE CODE
Coax card error Verify that the coax card is installed with the coax base
code.
WAITING CODE
DOWNLOAD
USING PARALLEL
PORT
Operator error Verify that you are using the Stop and Test keys at
power on to initiate test and diagnostics
TD 1 FRU 5 X
-or-
TD 1 FRU 4 X
Microcode/Hardware
Match Error
Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
TD 2 FRU 5 X
-or-
TD 2 FRU 4 X
Microcode Error Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
TD 3 FRU 2 2 Microcode Error Replace the logic board. See “Logic Board - Models
001 and 002” on page 378.
TD 4 FRU 5 X
-or-
TD 4 FRU 4 X
Microcode Error Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
Chapter 2. Diagnostics
231
