Table 28. T&D Error Messages and Actions (continued)
Error Message Description Action
TD 5 FRU 1 X Operator Panel
Failure
1. This error can occur if a key is not pressed in less
than 10 seconds. Run T&D05 again to verify the
problem.
2. Replace the operator panel. See “Operator Panel”
on page 355.
3. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
4. Replace the operator panel cable.
TD 6 FRU 0 X (*) Parallel Interface
Failure
Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
TD 8 FRU 0 X Microcode Error Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see “Logic
Board - Model 003” on page 366.
TD 10 FRU 0 1 (*) ASF/Stacker
Failure
1. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
2. Replace the stacker cable assembly.
TD 12 FRU 0 X AFTA Failure 1. See “Standard AFTA Service Check and
Adjustment” on page 285.
2. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
TD 14 FRU 0 20 Thermal Sense
Failure
1. Replace the printhead. See “Printhead” on
page 356.
2. Replace the logic board. See “Logic Board - Models
001 and 002” on page 378. For Model 003, see
“Logic Board - Model 003” on page 366.
3. Install new printhead cables.
Chapter 2. Diagnostics
232
