Reference Table 10, Ribbon Lift and 26–Pin Cable Connectors
Table 24. Connectors
Ribbon Lift Connector 26-Pin Connector
Pin 1 Pin 25
Pin 2 Pin 23
Pin 3 Pin 24
Pin 4 Pin 26
See “Wiring Diagrams” on page 240 for details on the location of the pins on the connector.
Reference Table 11, Paper Paths
Table 25. Guide and bail positions
Selected Paper Path Forms Guide Metal Deflector Paper Bail
Front Push Open Closed
Manual Sheet Feed Open Closed
Rear Push Open Closed
ASF Open Closed
Rear Pull Closed Removed
Front Push-Pull Closed Closed
Reference Table 12, Minimum Microcode
Table 26. Minimum Microcode Levels
Model Module Minimum Code Level
Controller Code Generator Code Attachment Code
Chapter 1. Diagnosing Problems
158
