Table 8. MAP 0130: No Paper Movement (continued)
Step Questions/Actions Yes No
4.
Disconnect the paper feed motor connector from the
logic board. See “Paper Feed Motor Wiring” on
page 248 to measure the resistance of the motor
windings.
Is the measurement correct for both windings?
Install a new logic board. For
Model A00, see “Logic Board -
Model A00” on page 370. For
Models 001 and 002, see “Logic
Board - Models 001 and 002” on
page 378. Or “Logic Board -
Model 003” on page 366.
-or-
Install a new paper drive motor.
See “Paper Feed Motor” on
page 447.
Run T&D in automatic mode to
verify correct printer operation.
For Model A00, see “How To
Run the Test and Diagnostic
(T&D) Programs” on page 161.
For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Install a new paper drive motor.
See “Paper Feed Motor” on
page 447. Run T&D in
automatic mode to verify correct
printer operation. For Model
A00, see “How To Run the Test
and Diagnostic (T&D) Programs”
on page 161. For Models 001,
002, or 003, see “How To Run
the Test and Diagnostic (T&D)
Programs” on page 201.
Chapter 1. Diagnosing Problems
65
