Asm–
Index
Part
Number Units Description
–4 08H7094 1 Support, Paper
–5 08H6952 1 1st Bin, Automatic Sheet Feeder Assembly
–6 08H7364 1 v Cover, Electronics Card
–7 08H7092 1 v Cap, left (Packaged 5 Per Pack)
–8 08H7365 1 v Deflector
–9 08H7093 1 v Cap, right (Packaged 5 Per Pack)
–10 08H7091 1 v Plate
–11 08H7368 1 v Kit, ASF Board and Cable
Assembly 2: (continued)
Chapter 6. Parts Catalog 464
