Table 13. MAP 0170: ASF Stacker (continued)
Step Questions/Actions Yes No
4.
Perform the main paper drive service check. See “Main
Paper Drive Check and Adjustment” on page 301.
Is the main paper drive service check OK?
Go to step 5. Repair as needed.
5.
Perform the Stacker Service Check. See “ASF Stacker
Service Check” on page 322.
Is the Stacker Service Check OK?
Go to step 6. Repair as needed.
6.
Do you have the stacker/ASF loop-back connector
(PN 08H7271)?
Go to step 7 on page 97. Install a new stacker assembly.
-or-
Install a new logic board. For
Model A00, see “Logic Board -
Model A00” on page 370. For
Models 001 and 002, see “Logic
Board - Models 001 and 002” on
page 378. Or “Logic Board -
Model 003” on page 366.
-or-
Install a new stacker cable.
Run T&D in Automatic Test
Mode to verify correct printer
operation. For Model A00, see
“How To Run the Test and
Diagnostic (T&D) Programs” on
page 161. For Models 001, 002,
or 003, see “How To Run the
Test and Diagnostic (T&D)
Programs” on page 201.
Chapter 1. Diagnosing Problems
96
