IBM 4247 User Manual

Table 27. T&D Error Messages and Action (continued)
Error Message Description Action
TD (**) FRU 3 13 Printhead Home Sense
Failure
1. See “Printhead Drive Service
Check” on page 333.
2. Replace the logic board.
See “Logic Board - Model A00” on
page 370.
3. Replace the sensor cable
assembly.
See “Sensor Cable Assembly” on
page 441.
TD (**) FRU 3 14 AFTA Failure 1. See “Standard AFTA Service Check
and Adjustment” on page 285.
2. Replace the logic board.
See “Logic Board - Model A00” on
page 370.
3. Replace the AFTA motor assembly.
See “Automatic Forms Thickness
Adjust (AFTA) Assembly” on
page 407.
TD (**) FRU 3 15 AFTA Failure 1. See “Standard AFTA Service Check
and Adjustment” on page 285.
2. Replace the logic board.
See “Logic Board - Model A00” on
page 370.
3. Replace the AFTA motor assembly.
See “Automatic Forms Thickness
Adjust (AFTA) Assembly” on
page 407.
Chapter 2. Diagnostics
194
