8. If an error message is displayed, go to “T&D Error Messages and Actions – Models 001, 002, and 003”
on page 231.
9. The test completed successfully if the display advances to the next test number.
T&D15 - First Printing Line Adjustment Test
This test allows you to adjust the first print-line for the front fanfold forms path and the rear fanfold forms path
from the operator panel.
The value set by this test becomes the first print-line position when the configuration menu item Paper Load
Position is set to 0.
Note: If you adjust this value you also must run T&D17
1. Display:
T&D15 First Printing Line Adjustment Test RUN TEST ? YES END NO
2. Press the Line Feed key.
If the following message displays, go to “T&D11 - Pinch Roller/Sensor Tune/Ribbon Feed and Lift
Motors” on page 208.
T&D15 First Printing Line Adjustment Test STORED PINCH XXXXX PRESS A KEY
Return here after the sensors are tuned.
Continue with the next step when the printer displays:
T&D15 First Printing Line Adjustment Test FANFOLD FRONT ADJ? YES NO
3. To adjust the first print-line for the front tractor feed, press the Line Feed key. The test will
automatically advance to the rear first print-line adjustment after you complete the front.
4. If you want to advance to the rear first print-line adjustment, now, press the Start key. The procedure
to adjust either front or rear first print-line is the same.
Chapter 2. Diagnostics 215
