Paper Feed Motor Wiring
The paper feed motor is a stepper motor with a 1.8° step angle. The motor connects directly to the logic board.
RESISTANCE MEASUREMENTS
4
1
3
4
1
2
VIEW FROM
WIRING SIDE
Figure 27. Carriage Motor Wiring
Chapter 3. Circuit Diagrams 248
