AFTA Motor Wiring
The AFTA motor is a stepper motor with a 3.6° step angle. The motor connects directly to the logic board.
RESISTANCE MEASUREMENTS
Figure 28. Paper Feed Motor Wiring
Chapter 3. Circuit Diagrams 250
