Ribbon Lift Motor Wiring
The ribbon lift motor is a linear actuator stepper motor with travel of 18 mm (0.71 inch). The motor connects to the
printhead, and the printhead cable connects to the logic board..
RESISTANCE MEASUREMENTS
Figure 30. Ribbon Feed Motor Wiring
Chapter 3. Circuit Diagrams 253
