12. Remove the operator panel cable wire tie from the front main cover if installed.
13. Remove the front and side mounting screws and remove the front and rear covers.
Replacement
1. Follow the removal steps in reverse order.
2. Perform the tear-off line adjustment. See “Tear-Off Line” on page 295.
Screws
Figure 101. Rear Main Cover Screws
Screws
Figure 102. Front Main Cover Screws
Chapter 5. Removals and Adjustments 352
