Cable Clamp
Screw
Ribbon
Lift
Connector
Print Head
Screws
e90aph1
Figure 106. Original Ribbon Lift Motor.
(Viewed From Top)
Printhead
Ribbon Lift
Motor Screws
Ribbon Lift Motor
Connector
Printhead
Cable
E90ARB12
Figure 107. New Ribbon Lift Motor.
(Viewed From Top)
Chapter 5. Removals and Adjustments 357
