Model 003 – Serial Card Jumper Locations
The Model 003 can also connect to a host using the serial attachment feature.
Figure 109 on page 363 shows the location of the jumpers that are mounted on to the serial card. These must be
in the correct location for the proper operation of the serial interface. Do not move these jumpers. Replace the
card if required.
E90APC14
Coax
IPDS
Module
Twinax
IPDS
Module
Figure 108. Location of IPDS modules on coax and twinax attachment cards
Chapter 5. Removals and Adjustments 362
