IBM 4247

Table 53. Module Reference List (continued)
Board Position Module Name Function
U37 L6219 Ribbon Drive Motor
U19 L293 Ribbon Lift Motor
U20 L293 Select Tractor Assembly Motor (inside)
U38 L6219 AFTA Motor
Q1 364–D2 AFTA Needle #5
Note: For the following lines, A = stationary side, B = moving side
01 = top most needles, 09 = bottom most needles
U31 L295 Needle 01 row a
Needle 06 row a
U32 L295 Needle 03 row a
Needle 04 row a
U33 L295 Needle 05 row a
Needle 09 row b
U30 L295 Needle 08 row a
Needle 09 row a
U29 L295 Needle 02 row b
Needle 07 row b
U28 L295 Needle 02 row b
Needle 08 row b
U26 L295 Needle 03 row b
Needle 06 row b
Chapter 5. Removals and Adjustments
388
