Table 4. MAP 0120: Attachment, Model A00 (continued)
Step Questions/Actions Yes No
6.
Do you have the parallel loop-back connector (PN
08H7269) for this printer?
Go to step 7. Install a new logic board. See
“Logic Board - Model A00” on
page 370. For Model 003, see
“Logic Board - Model 003” on
page 366.
-or-
Install a new host cable.
Run T&D in automatic mode to
verify correct printer operation.
See “How To Run the Test and
Diagnostic (T&D) Programs” on
page 161 for Model A00. For
Model 003, see “How To Run
the Test and Diagnostic (T&D)
Programs” on page 201.
7.
Install the loop-back connector.
Run T&D06 in Single Test Mode to test the parallel
attachment. See “How To Run the Test and Diagnostic
(T&D) Programs” on page 161 for Model A00. For
Model 003, see “How To Run the Test and Diagnostic
(T&D) Programs” on page 201.
Did T&D06 run without errors?
Install a new host parallel cable.
Run T&D in automatic mode to
verify correct printer operation.
For Model A00, see “How To
Run the Test and Diagnostic
(T&D) Programs” on page 161.
For Models 001, 002, or 003,
see “How To Run the Test and
Diagnostic (T&D) Programs” on
page 201.
Record the display message
and go to “T&D Error Messages
and Actions” on page 190 for
Model A00, or “T&D Error
Messages and Actions – Models
001, 002, and 003” on page 231
for Model 003, and perform the
suggested action.
Chapter 1. Diagnosing Problems
40
