IBM 4247

Asm–
Index
Part
Number Units Description
1–1 63H6004 1 Tray, Manual Sheet Feed
–2 63H6020 1 Cover, Front Main
–2A 4 Screw, Front Main Cover (PP 08H7356)
–3 08H7337 1 Cover, Left Side
–3A 1 Screw, Left Side Cover (PP 08H7356)
–4 63H6007 1 Cover, Top
–4A 08H7370 1 Magnet, Top Cover
–4B 63H6066 1 Kit, Top Cover Seals (7)
–5 08H7343 1 Cap, Stacker (Packaged 5 Per Pack)
–6 08H7344 1 Cap, Stacker (Packaged 5 Per Pack)
–7 08H7338 1 Cover, Right Side
–7A 1 Screw, Right Side Cover (PP 08H7356)
–8 63H6008 1 Guide, Forms
–9 08H7350 1 Panel, Operator, 4247 A00 (Also order item 9A)
–9A 1 v OVERLAYS:
–9A 08H6999 1 v English
–9A 08H7004 1 v Spanish
–9A 63H6068 1 v French
–9A 08H7014 1 v Italian
–9A 08H7019 1 v German
–9A 08H7024 1 v Dutch
–9A 08H7029 1 v Portuguese
–9A 08H7104 1 v Danish
–10 24H7580 1 Panel, Operator, 4247 Models 001, 002, and 003 (Also order item 10A or 10B)
–10A 1 v OVERLAYS: With Coax Attachment, Models 001, 002, and 003; with LAN feature or Parallel only,
Model 003:
–10A 63H6920 1 v English
–10A 63H6921 1 v Spanish
–10A 63H6922 1 v French
–10A 63H6923 1 v Italian
–10A 63H6924 1 v German
–10A 63H6925 1 v Dutch
–10A 63H6926 1 v Portuguese
Assembly 1: (continued)
Chapter 6. Parts Catalog 461
