IBM 4247

Asm–
Index
Part
Number Units Description
6– NP Mechanical Assembly
–1 2 v Screw, M3x8 (PP 08H7355)
–2 1 v Screw, M3x4 (PP 08H7355)
–3 08H7329 1 v Housing (Packaged 5 Per Pack)
–4 08H7395 1 v Bracket, Carriage Motor
–5 2 v Spacer (PP 08H7352)
–6 2 v Screw, M3x6 (PP 08H7355)
–7 08H7319 1 v Gear, AFTA Idler (Packaged 19 Per Pack)
–8 1 v Clip, Retaining (PP 63H6001)
–9 08H7320 1 v Motor Assembly, AFTA
–10 4 v Screw (PP 08H7355)
–11 2 v Retainer, Cable (PP 08H7352)
–12 01P7165 1 v Bail Assembly, Paper (Includes Bail, Coil Spring, and Upper Plastic Shield)
–12A 01P7164 1 v Kit, Bail Assembly (Upper Plastic Shield, Coil Spring and right end cap)
–13 02N7006 1 v Drive Kit, Left Ribbon (Includes support and drive shaft)
–16 08H7324 1 v Motor Assembly, Ribbon
–17 3 v Screw, M3x14 (PP 08H7355)
–18 4 v Screw (PP 08H7356)
–19 08H7325 1 v Support, Right Ribbon (Packaged 5 Per Pack)
–20 08H7326 1 v Indicator, AFTA (Packaged 5 Per Pack)
–21 08H7328 1 v Cover, Front Tractor Gear (Packaged 5 Per Pack)
–22 2 v Screw, M3x8 (PP 08H7355)
–23 1 v Washer (PP 63H6001)
–24 08H7248 1 v Cable, Tractor Assembly
–25 08H7250 1 v Cable, Stacker Assembly (Packaged 3 Per Pack)
–26 08H7360 2 v Housing, Tractor Cable Connector
–27 1 v Screw, M3x10 (PP 08H7355)
Assembly 6: (continued)
Chapter 6. Parts Catalog 474
