Asm–
Index
Part
Number Units Description
7–1 08H7264 1 Tie, Wire (Packaged 50 Per Pack)
–2 1 Screw (PP 08H7356)
–3 08H7252 1 Fan Assembly, Carriage Motor
–4 08H7258 1 Fan Assembly, Board
–5 08H7265 1 Bracket, Board Fan Support
–6 63H6245 1 Cover, Power Supply
–7 08H7262 1 Strip, Ground
–8 6 Screw, M3x6 with washer (PP 08H7355)
–9 2 Screw (PP 08H7355)
–10 NP Bracket, Power Connector
–11 1 Screw, M4x6 (PP 08H7355)
–12 1 Screw, M3x8 without washer (PP 08H7355)
–13 63H6010 1 Supply, Power, 220 V, 4247 A00, 001, 002
–13 08H7257 1 Supply, Power, 120 V, 4247 A00, 001, 002
–13 01P7580 1 Supply, Power, Auto-Ranging, 4247 003
–14 8 Screw (PP 08H7356)
–15 1 Board, Logic (See ELECTRONICS II)
–16 08H7367 1 Card, Serial Attachment, 4247 A00
–17 4 Screw, M3x8 with washer (PP 08H7355)
–18 1 Washer (PP 63H6001)
–19 08H7261 1 Strip, Ground
–20 2 Screw, M3x30 (PP 08H7355)
–21 1 Nut, M3 (PP 63H6001)
–22 1 Nut, M3 (PP 63H6001)
–23 NP Bracket
–24 AR Module, Microcode Models A00, 001, 002 (See ELECTRONICS II)
–25 01P7584 1 Cover Plate, Attachment Card, 4247 003, with 2 screws
–26 01P7585 1 Guide assembly, Attachment Card, 4247 003, with 2 support posts
–27 01P7621 1 Interposer Connector with Ground Strap, Attachment Card, 4247 003
–28 6 Screw, M3x4, without washer (PP08H7355)
–29 2 Screw, M3x4 with washer (PP08H7355)
Assembly 7: (continued)
Chapter 6. Parts Catalog 476
