Asm–

Index

Part

Number Units Description

8–4 63H6206 1 Board, Logic, 4247 A00, Level 4

–6 90H0026 1 Board, Logic, 4247 002, Level 2

–7 63H6208 1 Board, Logic, 4247 001, Level 3

–8 38L1210 1 Module, Microcode, 4247 A00, (compatible with both A00 early- and late-levels)

–9 24H7734 1 Module, Microcode, 4247 001, Coax SCS

–9A 24H7735 1 Module, Microcode, 4247 001, Coax IPDS

–10 24H7732 1 Module, Microcode, 4247 001, Twinax SCS

–10A 24H7733 1 Module, Microcode, 4247 001, Twinax IPDS

–11 24H7754 1 Module, Microcode, 4247 002, Coax SCS

–11A 24H7755 1 Module, Microcode, 4247 002, Coax IPDS

–12 24H7752 1 Module, Microcode, 4247 002, Twinax SCS

–12A 24H7753 1 Module, Microcode, 4247 002, Twinax IPDS

–13 38L1606 1 Card, Attachment, 4247 001, 002, Coax SCS

–13A 02N6102 1 Card, Attachment, 4247 001, 002, Coax IPDS

–14 38L1605 1 Card, Attachment, 4247 001, 002, Twinax SCS

–14A 02N6101 1 Card, Attachment, 4247 001, 002, Twinax IPDS

–15A 1 Module, Microcode U57, Model A00

–15B 1 Module, Microcode U57, Model 002

–15C 1 Module, Microcode U57, Model 001

–16 73G5523 AR Extractor, Microcode Module (For 4247 A00 with level 1 logic boards, you MUST use extractor

73G5523. For all other logic boards, you can use extractor 73G5523 or 10G3902.)

–16A 10G3902 NS Extractor, Microcode Module (Not Shown)

–17 01P7581 1 Board, Logic, 4247 003

–18 01P7574 1 Card, Attachment, 4247 Model 003, Twinax SCS

–18A 01P7575 1 Card, Attachment, 4247 Model 003, Twinax IPDS

–19 01P7576 1 Card, Attachment, 4247 Model 003, Coax SCS

–19A 01P7577 1 Card, Attachment, 4247 Model 003, Coax IPDS

–20 01P7578 1 Card, Attachment, 4247 Model 003, Serial

–21 01P7579 1 Card, Attachment, 4247 Model 003, Ethernet LAN Axis 10/100

– 27P8217 R Diskette, 4247 Model 003 Printer Code, 5.05 ASCII/Twinax (not shown)

– 27P8218 R Diskette, 4247 Model 003 Printer Code, 5.05 Coax (not shown)

Assembly 8: (continued)

Chapter 6. Parts Catalog 478

IBM 4247 User Manual
