Asm–
Index
Part
Number Units Description
–9 08H7320 1 Motor, AFTA
Includes Motor and Cable
–10 08H7258 1 Fan, Board
Includes Fan and Cable
–11 08H7252 1 Fan, Carriage Motor
Includes Fan and Cable
–12 08H7246 1 Printhead Assembly, 18-Wire (4247 A00, 001, 003)
–12 90H0024 1 Printhead Assembly, 9-Wire (4247 Model 002)
–13 63H6349 1 Bracket, Frame with M4x6 flathead screw
–14 1 Screw, Bracket (PP 08H7355)
–15 2 Screw, Printhead Mounting (PP 02N7555)
–16 4 Washer, 2 Star, 2 flat, Printhead Mounting (PP 02N7555)
–17 08H7253 1 Bracket, Printhead
–18 1 Screw, Bracket M4x6 flathead (PP 08H7355)
Assembly 9: (continued)
Chapter 6. Parts Catalog 480
