1 Fan door A
2 Fan door B
3 Cover release latch
4. Close the fan doors.
5. Replace the node in the rack.
Removing the service controller
You can remove the service controller from the SAN Volume Controller.
Removing the 2145-CG8 or 2145-CF8 service controller
DANGER
Multiple power cords. The product might be equipped with multiple power cords. To remove all
hazardous voltages, disconnect all power cords. (L003)
svc00322
1
2
or
1
2
svc00735
or
1
3
4
2
svc00734
This service action is used in two separate removal and replacement procedures, which each have unique
power requirements:
v If you are replacing the service controller, this service action requires you to turn off the node and
disconnect the USB service-controller cable.
1
2
3
svc00087
Figure 72. SAN Volume Controller 2145-8F2 with the access doors open
Chapter 2. Removing and replacing parts 85
|
|
|
|
|
|
|
|
||
|
||
|
|
|
|
|
|
To Next Page
