12. Replace fan 2.
13. Replace the cable connectors for fans 2 and 1, as shown in Figure 302.
1
Right disk signal cable connector
svc00379
Figure 301. Left air baffle on the SAN Volume Controller 2145-8G4
svc00377
3
4
2
1
5
Figure 302. Connectors on the SAN Volume Controller 2145-8G4 system board
300 IBM SAN Volume Controller Hardware Maintenance Guide
