Table 15. FRUs in the SAN Volume Controller 2145-8G4 parts assembly (continued)
Assembly index Part number Units Description
-8 and -15 26K8083 6 Fan assembly
- 33F8354 1 Battery, 3.0V
-9 43W0625 1 Operator-information panel
-10 31P0908 1 Service controller
-11 41Y8247 1 Hard disk drive, 3.5 in,
simple-swap SATA
(beginning with SAN
Volume Controller 4.3.1)
This disk drive, when
ordered as a replacement,
will be a supported
compatible drive of at least
the same capacity as the
one being replaced.
-12 32R2823 1 Simple-swap SATA disk
drive cage
-13 26K8060 1 Disk-drive backplane
-14 39Y6972 1 Power back plane
- 23R2770 1 Fibre Channel SFP
transceiver
- 31P1063 1 Power cable assembly
(SAN Volume Controller to
2145 UPS-1U)
- 39M5700 1 External Fibre Channel
cable, LC–LC, 5.0 m (16.4
ft)
- 39M5701 1 External Fibre Channel
cable, LC–LC, 25.0 m (82 ft)
- 59P4739 1 Alcohol wipe
- 41Y9292 1 Thermal grease
Table 16. FRUs that are not referenced by SAN Volume Controller 2145-8G4 service procedures
Part number Quantity Description
39Y9510 1 Kit, toolless rail
31P1045 1 Cable retainer assembly
26K8058 2 Front panel USB cable
32R2820 1 3.5 in. SATA service label
39Y9420 1 Air flow parts
39Y9423 2 Heat sink assembly
39Y9507 1 Media bezel assembly
43W0610 1 Service labels assembly
39Y9522 1 Main panel weldment
42C3983 1 Optical interposer card
43V4869 1 CRU/FRU label
Chapter 1. Parts listing 15
