v Table 5 on page 5 lists the FRUs that are not referred to by any SAN Volume Controller 2145-CG8
service procedure, but that might be replaced in some circumstances.
Table 4. FRUs in the SAN Volume Controller 2145-CG8 parts assembly
Assembly
index FRU part Quantity Description
- 1 43V7066 0-1 Empty riser card
The SAN Volume Controller 2145-CG8 slot 2 connector has one of
three adapters, either this one by default, or one of the optional
adapters.
- 1 31P1558 0-1 Optional high-speed SAS riser-card assembly
An assembly that includes a high speed SAS adapter card that
provides connectivity for up to four solid-state drives (SSD). The
assembly includes a riser card, a blanking plate, and two M3
screws.
- 41Y3884 0-1 High-speed SAS adapter cable
This cable connects the high-speed SAS adapter to the disk
backplane.
- 1 31P1559 0-1 Optional 10 gigabits-per-second (Gbps) Ethernet riser-card
assembly
An assembly that includes a 10 Gbps Ethernet adapter card that
provides connectivity for up to two 10 Gbps fiber optic Ethernet
cables. The assembly includes a riser card, a blanking plate, and
two M3 screws.
- 31P1549 0-2 10 Gbps Ethernet Fibre SW SFP
- 2 31P1337 1 4-port Fibre Channel adapter
The Fibre Channel host bus adapter (HBA) assembly connects the
SAN Volume Controller 2145-CG8 to the Fibre Channel fabric. It
is located in PCI slot 1. The adapter assembly includes the Fibre
Channel PCI Express adapter, four shortwave SFPs, the riser card,
and the bracket.
Important: If the system is using alternative SFPs, replace the
SFPs on the FRU part with the SFPs from the Fibre Channel
adapter that is being replaced.
- 31P1338 0-4 Shortwave SFP
The small form-factor pluggable (SFP) transceiver provides an
auto-negotiating 2, 4, or 8 Gbps shortwave optical connection on
the 4-port Fibre Channel adapter.
Important: It is possible that SFPs other than those shipped with
the product are in use on the Fibre Channel host bus adapter. It is
a customer responsibility to obtain replacement parts for such
SFPs. The FRU part number is shown as “Non standard -
supplied by customer” in the vital product data.
Chapter 1. Parts listing 3
|
|
|
|
|
||||
||||
|
|
|
||||
|
|
|
|
||||
|
|
||||
|
|
|
|
|
||||
||||
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
