IBM SAN Volume Controller 2145-CG8 User Manual

In the 2145-CF8 node, push the backplane backwards until it is clear of the slots on the bracket and
remove it from the node, as shown in Figure 115 on page 130.
2
1
2
3
Figure 114. The 2145-CG8 boot-disk backplane
Chapter 2. Removing and replacing parts 129
