Table 10. FRUs that are exchanged within SAN Volume Controller 2145-8A4 service procedures
Assembly index Part number Units Description
-2 41Y2854 4 Memory, 2 GB PC2-5300
ECC
-3 43W5112 1 Riser card, PCI Express
-4 31P0937 1 4-port Fibre Channel host
bus adapter
- 23R2770 4 Fibre Channel SFP
transceiver
-5 43W5103 1 System board (You need 1
alcohol wipe and 1 thermal
grease syringe when you
replace this FRU. If you do
not already have these,
order them before you
begin to replace the part.)
-6 39M4347 1 Disk cable assembly (A
SATA disk drive back plate
with 2 SATA cables)
-7 39Y7289 1 Power supply, 351 watt
-8 39M4322 5 Fan (40 mm)
-10 41Y8247 1 Hard disk drive, 3.5 in,
simple-swap SATA
This disk drive, when
ordered as a replacement,
will be a supported
compatible drive of at least
the same capacity as the
one being replaced.
-12 31P1157 1 Service controller, including
the front-panel display and
the display and control
buttons
-13 42C1513 1 Operator-information panel
- 39M6266 1 Operator-information panel
cable
-15 44X0204 1 Microprocessor, 3.0 GHz 6
MB dual core (You need 1
alcohol wipe and 1 thermal
grease syringe when you
replace this FRU. If you do
not already have these,
order them before you
begin to replace the part.)
- 33F8354 1 Battery, 3.0V
Chapter 1. Parts listing 11
